Laminated Yoke DC Motors



Laminated Yoke DC Motors



Specifications
Features
RANGE kW FRAME SIZE
Small 0.75 to 300 80 to 250
Medium 150 to 1500 280 to 630
Large 720 to 6500 710 to 1000 by centre height up to 3100 MM by rotor diameter
GENERAL SPECIFICATIONS
Standards BS 5000/IS 4722
Insulation CLASS F/CLASS H
Armature Voltage 110 to 1000 volts
Field Voltage 180 to 360 volts
Cooling IC 01/06/0041/0666/W37A86/17/44
Protection IP 23/44/54
Mounting B3/B35/B5/V1/V5



FRAME: KDLC 100-250
FRAME SIZE OUTPUT IN Max.Arm. Current Max. Safe Speed Excitation Power Time Constant for Field Ckt. Cooling Air Reqmt. Moment of Inertia GD2
  kW at 1500 RPM (A) (RPM) (Watts) (Secs) VOL. (Lts/sec) PR
WG
(kg M2)
KLDC 100SX
100MX
100LX
4.0
6.0
7.6
40 6000
6000
6000
350
450
600
0.08
0.08
0.10
50 35 0.100
0.132
0.164
KLDC 112SX
112MX
112LX
9.3
12.5
15.0
60 6000
6000
6000
750
900
1000
0.11
0.12
0.13
100 60 0.172
0.220
0.254
KLDC 132SX
132MX
132LX
18.75
25.00
28.00
105 5000
4800
4500
900
1000
1150
0.16
0.18
0.19
140 90 0.508
0.556
0.600
KLDC 160KX
160SX
160MX
160LX
30.00
37.00
45.00
56.00
240 4000
4000
4000
4000
900
950
1050
1150
0.24
0.26
0.28
0.30
290 100 0.72
0.96
1.08
1.40
KLDC 180SX
180MX
180LX
70.00
80.00
90.00
300 3750
3750
3500
1100
1250
1400
0.33
0.33
0.33
400 110 1.84
2.04
2.20
KLDC 200SX
200MX
200LX
110.00
130.00
150.00
385 3500
3500
3250
1450
1600
1850
0.43
0.43
0.43
510 135 3.24
3.64
4.28
KLDC 225SX
225MX
225LX
160.00
180.00
200.00
675 3000
3000
2600
1900
2100
2300
0.57
0.57
0.57
710 140 6.80
7.60
8.30
KLDC 250SX
250MX
250LX
235.00
260.00
300.00
750 2500
2500
2300
2350
2600
3000
0.71
0.71
0.71
850 150 11.6
13.2
15.8
For rating's other than those mentioned above, please send in your enquiries to the unit marketing.

FRAME: KDLC 280-630
FRAME SIZE OUTPUT IN kW at 1500RPM SPEED
(RPM)
Max.Arm. Current (A) Max. Safe Speed (RPM) Excitation Power (Watts) Force Cooling Unit Details Moment of Inertia GD2 (kg M2)
KLDC 280S
280M
280L
265.00
330.00
400.00
1750
1750
1750
800
800
800
2300
2300
2300
2200
2650
3200
3.7kW, 415V,
3phase, 50Hz,
2pole
19
24
28
KLDC 315S
315M
315L
320.00
400.00
460.00
1500
1500
1500
920
920
920
2000
2000
2000
2400
3000
3500
3.7kW, 415V,
3phase, 50Hz,
2pole
30
40
55
KLDC 355S
355M
355L
380.00
500.00
600.00
1250
1250
1250
1100
1100
1100
1900
1900
1900
2500
3350
4000
5.5kW, 415V,
3phase, 50Hz,
2pole
38
46
58
KLDC 400S
400M
400L
500.00
625.00
750.00
1000
1000
1000
1380
1380
1380
1700
1700
1700
3500
4400
5300
7.5kW, 415V,
3phase, 50Hz,
4pole
100
125
150
KLDC 450S
450M
450L
615.00
740.00
875.00
750
750
750
1380
1380
1380
1600
1600
1600
4600
5500
6500
7.5kW, 415V,
3phase, 50Hz,
4pole
145
175
230
KLDC 500S
500M
500L
635.00
790.00
950.00
750
750
750
1900
1900
1900
1400
1400
1400
4800
6000
7200
11kW, 415V,
3phase, 50Hz,
4pole
285
325
370
KLDC 560S
560M
560L
750.00
900.00
1050.00
500
500
500
1900
1900
1900
1300
1300
1300
6400
7600
9000
11kW, 415V,
3phase, 50Hz,
4pole
550
630
750
KLDC 630S
630M
630L
900.00
1150.00
1300.00
450
450
450
2100
2100
2100
1200
1200
1200
7400
9300
10500
15kW, 415V,
3phase, 50Hz,
4pole
1020
1170
1370


Download Brochure
